Fusion
Fusion El-f653w 6.5"" Speakers White 80 Watts
- SKU:
- WTFUS0100208002
- UPC:
- 753759314132
- MPN:
- 010-02080-02
- Shipping:
- Free Shipping
Description
Fusion EL-F653W 6.5"" Speakers White 80 Watts
Model: 010-02080-02- The injection-molded polypropylene cone provides clean, clear audio reproduction
- The shallow basket design provides increased versatility during installation.
- Salt fog resistant and UV stable design for the harsh marine environment.
The EL Series speakers have an IP65 rating for protection against dust and water ingress and have been tested to a high level of protection against salt fog and UV.
Tested to international standards for pressure and water ingress, the EL Series speakers are designed and built for superior quality and robustness.
The EL Series speakers incorporate high-quality materials and marine-specific design elements, ensuring they look and sound great on the water.
By using a water-resistant IMPP cone it improves the robustness of the speaker, allowing for clean, clear audio reproduction.
The lightweight design allows for higher sensitivity, resulting in increased power and efficiency to deliver an enhanced audio experience.
The optimized open back design allows for extended power handling and versatile mounting options with reduced mounting depth.
SpecificationsWater and dust rating | IP65 |
Configuration | Full range |
Speaker size | 6.5"" |
Peak power (Watts) | 80 W |
RMS power (Watts) | 20 W |
Sensitivity (1 W / 1 m) | 88 dB |
Frequency response | 45 Hz-16 kHz |
Nominal impedance | 4 ohms |
Recommended amplifier power (RMS) | 20-40 W/Ch |
Operating temperature range | 32° to 122° F (0° to 50° C) |
Voice coil diameter | 0.79"" |
Cone material | Polypropylene cone with cloth surround |
Compass-safe distance | 100"" (254 cm) |
Weight | 1.21 lbs (0.55 kg) |
Warranty | 1 year |
Mounting Dimensions | |
Mounting diameter clearance | 5.12"" (130 mm) |
Mounting depth clearance | 1.69"" (43 mm) |
Dimensions | 6.93" x 2.26" (176 x 57.5 mm) |
What's in the Box:
- One pair of speakers
- 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm (8 gauge x 1"))
- Two 20 ft (6 meter) speaker cables
- Documentation
