Fusion

Fusion El-f653g 6.5"" Speakers Gray 80 Watts

SKU:
WTFUS0100208023
UPC:
753759314170
MPN:
010-02080-23
Shipping:
Free Shipping
MSRP: $131.99
$109.99
ā€” You save $22.00

Description

Fusion EL-F653G 6.5"" Speakers Gray 80 Watts

Model: 010-02080-23
  • The injection-molded polypropylene cone provides clean, clear audio reproduction.
  • The shallow basket design provides increased versatility during installation.
  • Salt fog resistant and UV stable design for the harsh marine environment.

The EL Series speakers have an IP65 rating for protection against dust and water ingress and have been tested to a high level of protection against salt fog and UV.

Tested to international standards for pressure and water ingress, the EL Series speakers are designed and built for superior quality and robustness.

The EL Series speakers incorporate high-quality materials and marine-specific design elements, ensuring they look and sound great on the water.

By using a water-resistant IMPP cone it improves the robustness of the speaker, allowing for clean, clear audio reproduction.

The lightweight design allows for higher sensitivity, resulting in increased power and efficiency to deliver an enhanced audio experience.

The optimized open back design allows for extended power handling and versatile mounting options with reduced mounting depth.

Specifications
Water and dust ratingIP65
ConfigurationFull range
Speaker size6.5""
Peak power (Watts)80 W
RMS power (Watts)20 W
Sensitivity (1 W / 1 m)88 dB
Frequency response45 Hz-16 kHz
Nominal impedance4 ohms
Recommended amplifier power (RMS)20-40 W/Ch
Operating temperature range32° to 122° F (0° to 50° C)
Voice coil diameter0.79""
Cone materialPolypropylene cone with cloth surround
Compass-safe distance100"" (254 cm)
Weight1.21 lbs (0.55 kg)
Warranty1 year
Mounting Dimensions
Mounting diameter clearance5.12"" (130 mm)
Mounting depth clearance1.69"" (43 mm)
Dimensions 6.93" x 2.26" (176 x 57.5 mm)

What's in the Box:
  • One pair of speakers
  • 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm (8 gauge x 1"))
  • 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm (8 gauge x 1"))
  • Documentation
