13.875 X 13 Aluminium Three Blade Right Hand Rotation PROP HYDRUS (177203)

The 13.875 X 13 A3R PROP HYDRUS from Bombardier Recreational Products is a propeller (BRP). It's an aluminum-based material that gets tougher and more robust over time. It's a three-bladed propeller with a right-hand rotation. The calibration of pitch angles was changed to a higher one to increase performance and efficiency by speeding up and channeling water, eliminating slides while enhancing performance and efficiency. It's a tad heavier, weighing in at roughly 8 pounds. For navigational purposes, this weight is a good size. This slant improves the machine's overall performance and boat lift. In each rotation, the prop Hydrus has a diameter of 13.875 inches and a pitch distance of 9 inches.

Key features:

• Vents had been fine-tuning for a lightning-fast hole-shot.
• It increases handling and boat lift by having a steep rake.
• For quicker speeds, a blade design with a high rake is necessary.
• The performance of mid-range outboards has improved.
• The innovative blade profile provides optimal thrust in every water condition.
• Proven to produce superior performance "at work" and elsewhere

Product Details:

• SKU: 177203
• UPC: 824375016790
• Weight: 8.00 LBS
• MATERIAL: Aluminum
• PITCH: 13

Pontoons, high reverse thrust

Engine Application

2-Stroke 40-60 Horsepower Two Cylinder Large Gearcase, 55-75 Horsepower Three Cylinder 75-140 Horsepower Four Cylinder

40/50/60 hp (Evinrude® E-TEC™)…2004-thru, 45 hp (Commercial)…1986-thru;
50 hp… 1971-74;
50 hp (Commercial)…1980-thru;
55 hp (Commercial)…1980-thru;
55 hp…1968-69;
60 hp…1970-71;
60 hp…1986-96;
65 hp…1972-73;
65 hp (Commercial)…1984-2001;
70 hp…1974-2001;
75 hp (large gearcase)…1975-84;
75 hp…2004-thru;
85 hp…1969-80;
85 hp…1991-95;
88 hp…1981-thru;
90 hp…2004-thru;
90 hp…1981-thru;
100 hp…1979-80;
100 hp…1988-thru;
100 hp…2004-thru;
110 hp…1986-89;
115 hp…1973-thru;
120 hp1986-94;
125 hp…1971-72;
135 hp…1973-76;
140 hp…1977-84;
140 hp…1986-94

Attaching Hardware:H25

60-70 Horsepower 4-Stroke Continued

70 hp (Evinrude® & Johnson® 4 Cyl.)…1998;
70 hp (Evinrude 4 Cyl.)…1999-2001;
60-70 hp (Johnson 4 Cyl.)…2002-thru

Attaching Hardware:H23

Attaching Hardware

H25

Cotter pin:
Sierra: 18-3742
Cotter pin (100/box):
Other: 354622
Nut:
Sierra: 18-3705
Quicksilver: 859929
Spacer, nut, & pin kit:
Sierra: 18-3716
Quicksilver: 802010Q1
Splined spacer (aft):
Sierra: 18-4228
Quicksilver: 859892
Thrust washer (forward):
Sierra: 18-4222
Quicksilver: 859915

H23

Cotter pin:
Sierra: 18-3735
Flat washer:
Other: 5030441
Nut:
Sierra: 18-3726
Splined spacer washer (aft):
Sierra: 18-3798
Other: 5030925
Splined spacer, washer, nut & cotter pin kit:
Sierra: 18-3774
Thrust washer (forward) 60 hp '02-'03, 70 hp '01-'03:
Other: 5032551
Thrust washer (forward) 70 hp 1998, 2000 TNT (20" shaft):
Other: 5030924

H76

Cotter pin:
Sierra: 18-3742
Cotter pin (100/box):
Other: 354622
Nut:
Sierra: 18-3705
Quicksilver: 859929
Spacer, nut, & pin kit:
Sierra: 18-3716
Quicksilver: 802010Q1
Splined spacer (aft):
Sierra: 18-4228
Quicksilver: 859892
Thrust washer (forward):
Sierra: 18-4222
Quicksilver: 859915
Michigan Wheel: 991210

This product replaces:

824375016790, 175013, BRP175013, BRP177203, 177203
